7 Installation of FLUXUS G608 FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 49
• Remove the blind plug (see Fig. 7.9).
• Prepare the cable with an M20 cable gland.
• Push the cable through the cap nut, the compression part and the basic part of the ca-
ble gland (see Fig. 7.9).
• Insert the cable into the housing.
• Screw the gasket ring side of the basic part in the housing of the power adapter.
• Fix the cable gland by screwing the cap nut on the basic part of the cable gland.
• Connect the cable to the terminals of the power adapter (see Fig. 7.9 and Tab. 7.1).
• Connect the connector of the power adapter to the socket of the transmitter (see Fig.
7.9).
For the voltage see annex B, section Technical Data.
7.5 Connection of the Outputs (Optional)
The output adapter has to be used for the connection of the output adapters (see Fig.
7.10).
• Remove the blind plug.
• Prepare the output cable with an M20 cable gland.
• Push the output cable through the cap nut, the compression part and the basic part of
the cable gland (see Fig. 7.10).
• Insert the output cable in the housing (see Fig. 7.10).
• Screw the gasket ring side of the basic part in the housing of the power adapter.
• Fix the cable gland by screwing the cap nut on the basic part of the cable gland (see
Fig. 7.10).
• Connect the leads of the output cable to the terminals of the output adapter (see Fig.
7.10 and Tab. 7.2).
Tab. 7.1: Terminal assignment (power adapter)
terminal connection DC
(-) - DC
(+) + DC
Attention! Observe the Safety Instructions for the Use in Explosive Atmo-
sphere (see document SIFLUXUS_608).
