48 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 7 Installation of FLUXUS G608
7.4.2
Power Supply via the Power Cable and the Power Adapter (Optional)
The power adapter has to be used for the connection of the power cable.
Attention! Observe the Safety Instructions for the Use in Explosive Atmo-
sphere (see document SIFLUXUS_608).
Fig. 7.9: Connection of the power adapter
to the transmitter FLUXUS G608
blind plug
power cable
cap nut
compres-
sion part
basic part
gasket ring side
of the basic part
cable gland:
power adapter
CH A
COMM
OutputInput
DC-IN
CH B
