98 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 13 Advanced Measuring Functions
13.7.4 Measuring with Calculation Channels
Position the transducers for all activated measuring channels. The measurement will be
started automatically.
13.8 Change of the Limit for the Inner Pipe Diameter
It is possible to change the lower limit of the inner pipe diameter for a given transducer
type.
Enter HotCode 071001 immediately after the transmitter has been switched on.
Select program branch Measuring. Press ENTER.
Activate the necessary channels. Calculation channels are
activated or deactivated in the same way as the measuring
channels. Press ENTER.
If a measuring channel that is needed for an activated cal-
culation channel has not been activated, a warning will be
displayed. Press ENTER.
If a calculation channel is activated, the HumanMux mode
(see section 12.2.2) will be selected at the beginning of the
measurement and the values of the calculation channel
will be displayed.
If the AutoMux mode is selected, the measured values of
the measuring channels, but not the measured values of
the calculation channels, will be displayed alternately.
Press key to display the calculation function.
Press key to display the measured values of the differ-
ent channels.
Enter the lower limit of the inner pipe diameter of the dis-
played transducer type. Press ENTER to select the next
transducer type.
Note! If a transducer is used below its recommended inner pipe diameter,
a measurement might be impossible.
par >MEA< opt sf
Measuring
CHANN: A B >Y< Z
MEASUR .
WARNING! CHANNEL
B:INACTIV!
Y:Flow Velocity
53.41 m/s
