B Technical Data FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 189
B Technical Data
Flow Transmitter FLUXUS G601
FLUXUS G601
design portable
measurement
measuring principle transit time difference correlation principle
flow velocity
repeatability 0.15 % of reading
medium gases with a ratio of the characteristic acoustic impedances of pipe wall
and gas < 3000,
e.g. nitrogen, air, oxygen, hydrogen, argon, helium, ethylene, propane
temperature compen-
sation
corresponding to the recommendations in ANSI/ASME MFC-5M-1985
accuracy
- volumetric flow rate ± 1...3 % of reading depending on application
± 0.5 % of reading with field calibration
flow transmitter
power supply 100...240 V/50...60 Hz (power supply),
10.5...15 V DC (socket at transmitter )
or integrated battery
battery Li-Ion, 7.2 V/4.5 Ah
operating time (without outputs, inputs and backlight): > 14 h
power consumption < 6 W
number of flow mea-
suring channels
2
signal damping 0...100 s, adjustable
measuring cycle (1
channel)
100...1000 Hz
response time 1 s (1 channel), optional: 70 ms
housing material PA, TPE, AutoTex, stainless steel
degree of protection
according to EN 60529
IP 65
weight
fixation QuickFix pipe mounting fixture
operating temperature -10 ...+60 °C
display 2 x 16 characters, dot matrix, backlit
menu language English, German, French, Dutch, Spanish
measuring functions
physical quantities operational volumetric flow rate, standard volumetric flow rate, mass flow
rate, flow velocity
totalizers volume, mass
calculation functions average, difference, sum
diagnostic functions sound velocity, signal amplitude, SNR, SCNR, standard deviation of ampli-
tudes and transit times
0.01...35 m/s, pipe diameter dependent
