84 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 12 Displaying the Measured Values
12 Displaying the Measured Values
The physical quantity is set in the program branch Output Options (see section 12.1).
During the measurement, the designation of the physical quantity is displayed in the up-
per line, the measured value in the lower line. The display can be adapted (see section
12.3).
12.1 Selection of the Physical Quantity and of the Unit of
Measurement
The following physical quantities can be measured:
• sound speed
• flow velocity: is calculated on the basis of the measured transit time difference
• operating volumetric flow rate: is calculated by multiplying the flow velocity by the
cross-section of the pipe
• standard volumetric flow rate: is calculated on the basis of the operating volumetric
flow rate (see section 12.1.1)
• mass flow rate: is calculated by multiplying the volumetric flow rate by the operating
density of the medium
The physical quantity is selected as follows:
Press BRK to return to the main menu. The further menu items of the program branch
Output Options are for the activation of the measured value transmission.
Select the program branch Output Options. Press EN-
TER.
Select the channel for which the physical quantity is to be
entered. Press ENTER.
This display will not be indicated, if the transmitter has only
one measuring channel.
Select the physical quantity in the scroll list. Press ENTER.
For the selected physical quantity (except for the sound
speed), a scroll list with the available units of measure-
ment is displayed. The previously selected unit of mea-
surement is displayed first.
Select the unit of measurement of the selected physical
quantity. Press ENTER.
Note! If the physical quantity or the unit of measurement is changed, the
settings of the outputs will have to be checked (see chapter 21).
par mea >OPT< sf
Output Options
Output Options ↕
for Channel A:
Physic. Quant. ↕
act. Volume flow
