FLUXUS G60x 21 Outputs
21.8 Deactivation of the Outputs
If the programmed outputs are no longer required, they can be deactivated. The configu-
ration of a deactivated output is stored and will be available if the output is activated
again.
Tab. 21.6: Pictograms for the alarm state indication
no. func
(switching condition)
typ
(holding behavior)
mode
(switching function)
current
state
R=
1 OFF NON-HOLD NO Cont. closed
2 MAX HOLD NC Cont. open
3 MIN
+
→- -→+
QUANT.
ERROR
Select no in Output Options\Alarm Output to deac-
tivate an output. Press ENTER.
