14 Data Logger and Transmission of Data FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 99
14 Data Logger and Transmission of Data
The transmitter has a data logger in which the measured values are stored during the
measurement (see section 14.1).
The measured values are transmitted to a PC via the serial interface directly during the
measurement (see section 14.2).
For the connection of the serial interface see section 6.7.
14.1 Data Logger
The following data will be stored:
• date
•time
• measuring point number
• pipe parameters
• medium parameters
• transducer data
• sound path (reflection or diagonal mode)
• transducer distance
• damping factor
• storage rate
• physical quantity
• unit of measurement
• measured values (physical quantity and input quantities)
• totalizer values (if the totalizers are activated)
• diagnostic values (if storing of diagnostic values is activated)
In order to store the measured data, the data logger must be activated (see section
14.1.1).
The available data logger memory can be displayed (see section 14.1.6).
The storing of each measured value will be signaled acoustically. This signal can be de-
activated (see section 14.1.3 in Acoustic Signal).
14.1.1 Activation/Deactivation of the Data Logger
Select in the program branch Output Options the chan-
nel for which the data logger is to be activated. Press
ENTER.
This display will not be indicated if the transmitter has only
one measuring channel.
Output Options ↕
for Channel A:A
