50 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 7 Installation of FLUXUS G608
• Remove the socket cover from the transmitter for the connection of the output adapter
(see Fig. 7.5).
• Connect the connector of the output adapter to the socket.
Fig. 7.10: Connection of the output adapter
to the transmitter FLUXUS G608
output cable
cap nut
compres-
sion part
basic part
cable gland:
blind plug
output
adapter
CH A
COMM
OutputInput
DC-IN
CH B
gasket ring side
of the basic part
