52 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 7 Installation of FLUXUS G608
7.6.2 Input Adapter (Optional)
The number of temperature inputs can be increased to max. 4 by means of 2 input adapt-
ers (see Fig. 7.12).
Fig. 7.12: Connection of the input adapters
T3
T2
T4
input adapter
T1
