FLUXUS G60x 21 Outputs
21.6.2 Setting the Limits
If the switching condition MAX or MIN has been selected in the scroll list func, the limit of
the output will have to be defined:
If the switching condition QUANT. has been selected in the scroll list func, the limit of the
output will have to be defined:
Select in the scroll list Input the physical quantity to be
used for the comparison. The following list items are avail-
able:
• selected physical quantity
• signal amplitude
• sound speed of the medium
Press ENTER.
switching condition: MAX
Enter the upper limit. Press ENTER.
The alarm will switch if the measured value exceeds the
limit.
switching condition: MIN
Enter the lower limit. Press ENTER.
The alarm will switch if the measured value falls below the
limit.
example 1: High Limit:: -10 m
3
/h
volumetric flow rate = -9.9 m
3
/h
the limit is exceeded, the alarm switches
volumetric flow rate = -11 m
3
/h
the limit is not exceeded, the alarm does not switch
example 2: Low Limit:: -10 m
3
/h
volumetric flow rate = -11 m
3
/h
the measured value is below the limit, the alarm switches
volumetric flow rate = -9.9 m
3
/h
the measured value is not below the limit, the alarm does not switch
switching condition: QUANT.
Enter the limit of the totalizer. Press ENTER.
The alarm will switch if the measured value reaches the
limit.
R1 Input: ↕
act. Volume flow
High Limit:
-10.00 m3/h
Low Limit:
-10.00 m3/h
Quantity Limit:
1.00 m3
