40 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 6 Installation of FLUXUS G601
6.6.3 Input Adapter
The number of temperature inputs can be increased to max. 4 by means of 2 input adapt-
ers (optional) (see Fig. 6.11).
If the transmitter has voltage or current inputs, the adapter for voltage and current inputs
will be used (see Fig. 6.12).
Fig. 6.11: Connection of the input adapters
T3
T2
T4
input adapter
T1
