9 Installation of the Temperature Probe (Optional) FLUXUS G60x
UMFLUXUS_G6V4-2DE, 2011-03-29 65
Fig. 9.9: Transmitter FLUXUS G608
Tab. 9.1: Connection of the temperature probe
direct connection
connection via
extension cable (optional)
CH A
COMM
OutputInput
DC-IN
CH B
temperature inputs
transmitter transmitter
temperature probe
transmitter transmitter
extension cable
temperature probe
