Ethernet Port Configuration
4.2.1.4 Configure Default VLAN
Table 4-5 Configure default VLAN
Enter global configuration mode
Enter interface configuration mode
interface ethernet
device-num/slot-num/port-num
switchport default vlan vlan_id
Example:
! The first four ports (e 0/0/1 – e0/0/4）connect to different server. These four servers
should be isolated. And the servers belong to VLAN 10，VLAN 20，VLAN 30 and VLAN 40
Switch(config)#vlan 10
Switch(config-if-vlan)#switchport ethernet 0/0/1
Add VLAN port successfully.
Switch(config-if-vlan)#vlan 20
Switch(config-if-vlan)#switchport ethernet 0/0/2
Add VLAN port successfully.
Switch(config-if-vlan)#vlan 30
Switch(config-if-vlan)#switchport ethernet 0/0/3
Add VLAN port successfully.
Switch(config-if-vlan)#vlan 40
Switch(config-if-vlan)#switchport ethernet 0/0/4
Add VLAN port successfully.
Switch(config-if-vlan)#interface ethernet 0/0/1
Switch(config-if-ethernet-0/0/1)#switchport default vlan 10
Switch(config-if-ethernet-0/0/1)#interface ethernet 0/0/2
Switch(config-if-ethernet-0/0/2)#switchport default vlan 20
Switch(config-if-ethernet-0/0/2)#interface ethernet 0/0/3
Switch(config-if-ethernet-0/0/3)#switchport default vlan 30
Switch(config-if-ethernet-0/0/3)#interface ethernet 0/0/4
Switch(config-if-ethernet-0/0/4)#switchport default vlan 40
Switch(config-if-ethernet-0/0/4)#vlan 1
Switch(config-if-vlan)#no switchport ethernet 0/0/1 to ethernet 0/0/4
Switch(config-if-vlan)#show interface brief e 0/0/1 to e 0/0/4
Port Desc Link shutdn Speed Pri PVID Mode TagVlan UtVlan
e0/0/1 down false auto 0 10 hyb 10
