Scan Options
83
Copy
3
îš„Side 2
z
Same as Side 1
Select this item when you want the same edge erase setting for both Side 1 and Side 2.
z
Opposite to Side 1
Select this item when you want the symmetry edge erase settings for both Side 1 and
Side 2.
When Border Erase is selected:
You can specify the same value for the top, bottom, left and right edges.
1 Select [Border Erase].
2 Use [ ] and [ ] to enter the value
for the Edge Erase.
îš„4 Edges
Erases shadows at the top, bottom, left and right of the copies. Edges at the top and
bottom are erased in accordance with the direction that the copies are loaded. You can
set the border erase width within the range from 0 to 50 mm in 1 mm increments.
îš„Center
Shadows in the center of documents such as booklets or documents with facing pages
are erased. You can set the center erase width within the range from 0 to 50 mm in 1
mm increments.
îš„Original Orientation
Refer to "Original Orientation (Specify the Orientation of Loaded Documents)" (P.88).
To Next Page
