Fujitsu ScanSnap N1800 User Manual

103
2. Set the area for multifeed detection in the [Ultrasonic Multifeed Detection
Zone] section.
Starting from the top edge of a document sheet, set the area to be checked for
multifeeds.
3. In
Step 2, if [Middle] or [Top & Bottom] is selected, enter both "#1" (upper
limit) and "#2" (lower limit).
z Middle
Multifeeds will be detected within "#1" (upper limit) and "#2" (lower limit) set. (a)
Multifeed may not be detected for the top and bottom 30 mm of a document.
25 mm
25 mm
Center of paper
Up to 510 mm
Outside of multifeed
detection area
(a)
#2
#1

Fujitsu ScanSnap N1800 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Output color depth	24 bit
ADF scan speed (color, A4)	20 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (color, A4)	20 ipm
Display	TFT
Scanner type	ADF scanner
Product color	Black, Grey
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Fax, File, FTP, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	12000 pages per month
Daily duty cycle (max)	2000 pages
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Auto document feeder (ADF) input capacity	50 sheets
Safety	LDAP, LDAPS, FTPS, HTTPS
Cabling technology	10BASE-T, 100BASE-TX
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage	100-240 V
Power supply type	AC
Power consumption (off)	0.5 W
Power consumption (standby)	15 W
Power consumption (typical)	50 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Depth	226 mm
Width	300 mm
Height	172 mm
Weight	6000 g
