4.9 Configuring the LDAP Settings
4.9.1 Setting the Login LDAP Server
If a login LDAP server is set, user authentication will be checked.
1. Select [Network Settings]
J [Authentication Server] J [Login LDAP
Server].
D The [Login LDAP Server] window appears.
2. For [Server Type], set the connection settings for the login LDAP server.
Select [Off] if an LDAP server is not required for user logins. No other settings can
be entered. Press the [OK] button to confirm the setting.
3. For [SSL], select whether or not to enable SSL.
4. Enter the LDAP server IP address, host name, or FQDN in the [Address]
input field
5. In the [Port Number] input field, enter a port number to be used by the
scanner to communicate with an LDAP server.
6. In the [Search Base (DN)] input field, enter the distinguished name of the
LDAP search base.
The LDAP entries under the character string entered here will become the search
target.
For details about the character string to be entered, and connection to the LDAP
search target, refer to
"LDAP Search Target" (page 129).
Central Admin
Console

Fujitsu ScanSnap N1800 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Output color depth	24 bit
ADF scan speed (color, A4)	20 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (color, A4)	20 ipm
Display	TFT
Scanner type	ADF scanner
Product color	Black, Grey
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Fax, File, FTP, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	12000 pages per month
Daily duty cycle (max)	2000 pages
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Auto document feeder (ADF) input capacity	50 sheets
Safety	LDAP, LDAPS, FTPS, HTTPS
Cabling technology	10BASE-T, 100BASE-TX
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage	100-240 V
Power supply type	AC
Power consumption (off)	0.5 W
Power consumption (standby)	15 W
Power consumption (typical)	50 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Depth	226 mm
Width	300 mm
Height	172 mm
Weight	6000 g
