Fujitsu ScanSnap N1800 User Manual

6.3 Logging in: Regular User Mode
306
6.3 Logging in: Regular User Mode
Depending on the authentication mode and the specified user name, the following
authentication process is performed for login authentication.
z For users registered in the LDAP server
Specify a user name from the user information registered with the LDAP server.
z When the [Server Type] of the LDAP server is [Active Directory] or [Active
Directory Global Catalog]
z When the [Server Type] of the LDAP server is [Other LDAP Server]
z For users registered in a local account
Specify a user name from the user information of the local account.
Authentication is performed with a specified user login name for a local account saved
in a scanner.
Note that the authenticated user info is also used when saving scans to a network folder.
When the scanner is turned on or restarted, automatic login without displaying the [Login]
window is possible.
Login is not possible if the Active Directory account option is "User must change
password at next logon". Contact an administrator to change a password, and then try
logging in.
CAUTION
Do not move or shake the scanner when it is turned on.
This may damage components in the scanner and cause data to be
lost.
User Name Format Authentication Process
SAM Account Name
Does not contain @
Authenticate the user login name
(sAMAccountName).
Example: user
User Principal Name
Contains @
Authenticate the user login name
(userPrincipalName).
Example: user@example.com
User Name Format Authentication Process
uid Authenticate the user login name (uid).
Example: user
cn Authenticate the user login name (cn).
Example: user

Fujitsu ScanSnap N1800 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Output color depth	24 bit
ADF scan speed (color, A4)	20 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (color, A4)	20 ipm
Display	TFT
Scanner type	ADF scanner
Product color	Black, Grey
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Fax, File, FTP, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	12000 pages per month
Daily duty cycle (max)	2000 pages
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Auto document feeder (ADF) input capacity	50 sheets
Safety	LDAP, LDAPS, FTPS, HTTPS
Cabling technology	10BASE-T, 100BASE-TX
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage	100-240 V
Power supply type	AC
Power consumption (off)	0.5 W
Power consumption (standby)	15 W
Power consumption (typical)	50 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Depth	226 mm
Width	300 mm
Height	172 mm
Weight	6000 g
