Fujitsu ScanSnap N1800 User Manual

4.8 Configuring the Network Settings
118
4.8.5 Setting the Proxy Server
Set whether a proxy server is used when connecting to the FTP server or SharePoint
server.
When a proxy server is used for update check, an HTTP proxy server should be set.
1. Select [Network Settings] J [Basic] J [Proxy Server].
D The [Proxy Server] window appears.
2. Use the [FTP Proxy Server] option to set whether or not a proxy server is
used for FTP server connection.
3. When a proxy server is used, set the address and port number.
4. For [HTTP Proxy Server], set whether or not a proxy server is used for
the SharePoint server connection or for the update check.
5. When a proxy server is used, set the address, port number, and
exceptions.
6. Press the [OK] button.
D The information entered is set.
Central Admin
Console
To enable the proxy server setting for each FTP server folder, the [FTP Proxy
Server] setting must be set to [On].
If the [FTP Proxy Server] setting is set to [Off], the proxy server cannot be set
for each FTP server folder in the FTP server folder setting window or the FTP
server folder cannot be accessed.
This scanner uses FTP over HTTP to save data in an FTP server folder via a
proxy. Specify the HTTP proxy server address for the FTP proxy server
address.

Fujitsu ScanSnap N1800 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Output color depth	24 bit
ADF scan speed (color, A4)	20 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (color, A4)	20 ipm
Display	TFT
Scanner type	ADF scanner
Product color	Black, Grey
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Fax, File, FTP, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	12000 pages per month
Daily duty cycle (max)	2000 pages
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Auto document feeder (ADF) input capacity	50 sheets
Safety	LDAP, LDAPS, FTPS, HTTPS
Cabling technology	10BASE-T, 100BASE-TX
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage	100-240 V
Power supply type	AC
Power consumption (off)	0.5 W
Power consumption (standby)	15 W
Power consumption (typical)	50 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Depth	226 mm
Width	300 mm
Height	172 mm
Weight	6000 g
