Fujitsu ScanSnap N1800 User Manual

5.11 Updating the Scanner Settings
266
5.11 Updating the Scanner Settings
The scanner settings can be updated by uploading new sets of scanner settings and
setting update calls.
The new set of scanner settings will be released, and applied to the scanners when one of
the following occurs:
z Scanner is started, or resumed from the standby mode
z Scanner is logged out
z Scanner is notified of any update modules
z Scanner has an automatic update scheduled
When update calls are set up, updates can be applied to the scanners that are in power-
off or standby mode using Wake-On-LAN.
If the update is released while the user is logged into a scanner, the module will be
applied after you log out.
If scanner settings are already available, the scanner settings are replaced.
1. Press the [Admin Operations] button in the Central Admin Console main
window.
D The [Scanner Admin Operations] window appears.
2. Select the [Scanner Settings] link.
D The [System Settings] window appears.
The scanner settings can be updated according to the time specified on the scanner
side.
For details, refer to
"4.8.9 Setting a Central Admin Server" (page 125).

Fujitsu ScanSnap N1800 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Output color depth	24 bit
ADF scan speed (color, A4)	20 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (color, A4)	20 ipm
Display	TFT
Scanner type	ADF scanner
Product color	Black, Grey
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Fax, File, FTP, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	12000 pages per month
Daily duty cycle (max)	2000 pages
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Auto document feeder (ADF) input capacity	50 sheets
Safety	LDAP, LDAPS, FTPS, HTTPS
Cabling technology	10BASE-T, 100BASE-TX
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage	100-240 V
Power supply type	AC
Power consumption (off)	0.5 W
Power consumption (standby)	15 W
Power consumption (typical)	50 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Depth	226 mm
Width	300 mm
Height	172 mm
Weight	6000 g
