4.2 Administrator Login
86
Uninstalling the Admin Tool
This section uses Windows Vista as an example.
Uninstall the Admin Tool from [Control Panel] - [Programs] - [Programs and Features] in
the computer in which it is installed.
z If this tool has already been installed, skip to section "4.2.3 Administrator Login: via
the Admin Tool" (page 87)
for details about Admin Tool operations.
z From the Web browser [Tools] menu, select [Internet Options], and note the
following points about the settings shown on the [Internet Options] dialog box.
z In the [Accessibility] dialog box shown when pressing the [Accessibility] button
on the [General] tab, do not change the formatting and user style sheet
settings. If these settings are changed, the displayed style of the Admin Tool
may be corrupted.
z In the [Language Preference] dialog box shown when pressing the
[Languages] button on the [General] tab, move the same language as for the
Central Admin Server operation system to the top. If a different language is
specified, a problem may occur with the input or displays for the Admin Tool.
z On the [Security] tab, if [Security level for this zone] is set to [High], part of the
Admin Tool window may not be correctly displayed.
In this case, on the [Security] tab, add the scanner or Central Admin Server to
the trusted site zone and press the [Default Level] button. Or press the [Custom
Level] button and set [Binary and script behaviors] to [Enable].
z When the font size is large, part of the dialog box may not be shown correctly. In this
case, use a smaller font size.
Close the Admin Tool before uninstalling.
If the Admin Tool is uninstalled while still open, normal operation of the open Admin
Tool is not guaranteed.

Table of Contents

Other manuals for Fujitsu ScanSnap N1800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu ScanSnap N1800 and is the answer not in the manual?

Fujitsu ScanSnap N1800 Specifications

General IconGeneral
Film scanningNo
Color scanningYes
Input color depth- bit
Maximum scan size216 x 356 mm
Output color depth24 bit
ADF scan speed (color, A4)20 ppm
Optical scanning resolution600 x 600 DPI
Duplex ADF scan speed (color, A4)20 ipm
DisplayTFT
Scanner typeADF scanner
Product colorBlack, Grey
Display diagonal8.4 \
Display resolution1024 x 768 pixels
Scan toE-mail, Fax, File, FTP, Image
Sensor typeCCD
Scan file formatsJPG, PDF, TIFF
Maximum duty cycle12000 pages per month
Daily duty cycle (max)2000 pages
Minimum scan area (ADF)50.8 x 50.8 mm
ISO A-series sizes (A0...A9)A4, A5, A6, A7, A8
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight52 - 127 g/m²
Auto document feeder (ADF) input capacity50 sheets
SafetyLDAP, LDAPS, FTPS, HTTPS
Cabling technology10BASE-T, 100BASE-TX
Networking featuresFast Ethernet
Supported network protocolsTCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage100-240 V
Power supply typeAC
Power consumption (off)0.5 W
Power consumption (standby)15 W
Power consumption (typical)50 W
Sustainability certificatesENERGY STAR
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
CertificationRoHS
Weight and Dimensions IconWeight and Dimensions
Depth226 mm
Width300 mm
Height172 mm
Weight6000 g
