D Follow the instructions displayed on the window.

When "Installation complete" is displayed, the installation is complete. Press the

[Close] button.

D After installation is completed, log out from the scanner on the Web browser and

close the Web browser.

D After installation, the Central Admin Console can be started by selecting the

[Start] menu - [All Programs] - [Scanner Central Admin Server] - [Scanner

Central Admin Console].

z If an older version of Central Admin Console is installed, uninstall it before installing

the latest version of Central Admin Console.

z From the Web browser [Tools] menu, select [Internet Options], and note the

following points about the settings shown on the [Internet Options] dialog box.

z In the [Accessibility] dialog box shown when pressing the [Accessibility] button

on the [General] tab, do not change the formatting and user style sheet

settings. If these settings are changed, the displayed style of the Central Admin

Console may be corrupted.

z In the [Language Preference] dialog box shown when pressing the

[Languages] button on the [General] tab, move the same language as that of

the Central Admin Server's operating system to the top. If a different language

is specified, a problem may occur with the input or displays for the Central

Admin Console.

z On the [Security] tab, if [Security level for this zone] is set to [High], part of the

Central Admin Console window may not be correctly displayed.

In this case, on the [Security] tab, add the scanner or Central Admin Server to

the trusted site zone and press the [Default Level] button. Or press the [Custom

Level] button and set [Binary and script behaviors] to [Enable].

z On the [Advanced] tab, select the [Play animations in webpages] check box

under [Multimedia].

In Windows Server 2003 or Windows Server 2008, this check box is not

selected by default.

z When the font size is large, part of the dialog box may not be shown correctly. In this

case, use a smaller font size.

z For details about the operating environment required for installing the Central

Admin Server software, refer to

"1.4.2 Requirements for Central Admin Console"

(page 47)

z When installing the Central Admin Console, the same necessary pre-settings

before logging in with the Admin Tool are required. For details, refer to

"4.2.2 Setting

up for Administrator Access via the Admin Tool" (page 80)

Fujitsu ScanSnap N1800 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Output color depth	24 bit
ADF scan speed (color, A4)	20 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (color, A4)	20 ipm
Display	TFT
Scanner type	ADF scanner
Product color	Black, Grey
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Fax, File, FTP, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	12000 pages per month
Daily duty cycle (max)	2000 pages
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Auto document feeder (ADF) input capacity	50 sheets
Safety	LDAP, LDAPS, FTPS, HTTPS
Cabling technology	10BASE-T, 100BASE-TX
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage	100-240 V
Power supply type	AC
Power consumption (off)	0.5 W
Power consumption (standby)	15 W
Power consumption (typical)	50 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS
