Section 4
4-48 © Copyright 2009 GBC. All rights reserved. Advanced Punch Service Manual
4.9 Punch Module
Maintenance Schedule
Lubricate cams every 750K cycles with teflon grease.
Tools Required
• Phillips screw driver or 1/4" nut driver
• Hex wrench, 5/64"
Tip: Empty the paper chip bin and replace it. This makes it easier to find
small parts that you may drop into the bin.
Procedure
Remove the module to lubricate the cams, or to service or replace the following
components.
• Drive motor
• Drive motor belt
• Brake
• Cams
• Flexible drive coupling
• Punch Module drive rollers
The clutch can be replaced without removing the module. See “Clutch
Replacement” on page 4-55.
Warning: Disconnect the Advanced Punch from its power source before removing the
Back Gauge assembly. Failure to observe this warning can result in severe injury or death
and damage the punch.
