Repair and Adjustment Procedures
Advanced Punc
h Service Ma
nual
© Copyright 2009 GBC. All rights reser
ved.
4-55
4.9.3
Clutc
h Replacement
Procedure
Replace if clutch is malfunctioning.
Note:
The c
lutch can be
remov
e
d without re
moving the Punch Mo
dule.
T
ools Required
•
Phillips screwdriv
er or 1/4" nut driver
•
He
x wrench, 5/64"
T
o remove the clutc
h:
1.
Unplug the fl
ag sensor connector [1].
Figure 4.60 Fla
g Sensor Connector on Rear
of the Punch.
[1]
112
