GBC AdvancedPunch User Manual

Section 6
6-8 © Copyright 2009 GBC. All rights reserved. Advanced Punch Service Manual
6.6 GBC AdvancedPunch Fault Code List
Chain
No
Link
No
Fault Name Description Corrective Action Function
Inhibited
after
Occur-
rence
40 100 AdvancedPunch
Bypass Jam
AdvancedPunch Jam is detected
when the paper is transported
through the AdvancedPunch Bypass
Path.
AdvancedPunch Front
Door Open/Close, plus no
AdvancedPunch Jam
Print
40 101 AdvancedPunch
Path Jam
AdvancedPunch Jam is detected
when the paper is transported
through the AdvancedPunch Path.
AdvancedPunch Front
Door Open/Close, plus no
AdvancedPunch Jam
Print
40 900 Paper Remain at
AdvancedPunch
Bypass
Paper remaining on the Advanced-
Punch Bypass Path is detected.
AdvancedPunch Front
Door Open/Close, plus no
AdvancedPunch Jam
Print
40 901 Paper Remain at
AdvancedPunch
Path
Paper remaining on the Advanced-
Punch Path is detected.
AdvancedPunch Front
Door Open/Close, plus no
AdvancedPunch Jam
Print
40 300 AdvancedPunch
Front Door Open
AdvancedPunch Front Door being
opened is detected.
AdvancedPunch Front
Door Close
Print
40 940 AdvancedPunch
Die Miss Set
When the Punch Die is not set in
AdvancedPunch, the IFM notifies the
status. Then, Controller creates the
corresponding Chain Link.
Punch Die Set Punch
40 941 AdvancedPunch
Dust Box Miss
Set
When the Punch Dust Box is not set
in AdvancedPunch, the IFM notifies
the status. Then, Controller creates
the corresponding Chain Link.
Punch Dust Box Set Punch
40 942 AdvancedPunch
Dust Box Full
When the status of punch waste full
is detected in AdvancedPunch, the
IFM notifies the status. Then, Con-
troller creates the corresponding
Chain Link.
Front Door Open --> Punch
Dust Box pull out --> Punch
Dust Box Set --> Front
Door Close
After the above procedure,
AdvancedPunch notifies
Not Full.
Punch
140 700 AdvancedPunch
Dust Box Near
Full
When the status of punch waste
almost full (Near Full) is detected in
AdvancedPunch, the IFM notifies the
status and also Chain Link.
Front Door is Open and
Punch Dust Box is pulled
out (not set) for 5 seconds.
