Section 6
6-10 © Copyright 2009 GBC. All rights reserved. Advanced Punch Service Manual
6.9 Principle of Operation
The GBC Advanced Punch is a machine that punches various die set hole
patterns into single sheets of paper. The machine is placed between a printer or
copier and a finisher. The punch has two paper paths.
• The bypass section.
• The punch path.
The bypass moves the paper from the printer to the finisher without punching
holes. The punch path routes the paper from the printer through the punch to be
punched and then routes the paper to the finisher. The punch path can be
selected by pressing the green button on the top of the Advanced Punch.
The Advanced Punch consists of several input and output devices to operate the machine
functions. The system intelligence is a Microchip micro-controller PIC17C752. The I/O
devices are listed in the tables below.
Refer to the electrical wiring information, when reading the following material. Also refer
to Figure 6.1.
6.9.1 Inputs
The input signals can be verified using the printer routines using NVMs.
Table 6.1Input Devices
Input Type Function
Sensor 1 Optical Sheet speed measurement, misfeed detect
Sensor 2 Optical Stepper 1 control, Sheet speed measurement, misfeed
detect
Sensor 3 Optical Punch mechanism control, Backstop raiser, misfeed
detect
Sensor 4 Optical misfeed detect at entrance of U-Channel
Sensor 5 Optical Jam detection
Sensor 6 Optical Stepper 2 Control, misfeed detect
Sensor 7 Optical Exit sensor, misfeed detect
Sensor 8 Optical Bypass sensor, Sheet speed measurement, misfeed
detect
Sensor 9 Optical Vane Monitors rotation of punch mechanism, Controls clutch
and brake
Switch 2A Mechanical Interlock Voltage, no machine movement if door is open
Switch 2B Mechanical Door open signal
Switch 3 Mechanical Chip tray switch
Switch 4 Mechanical Die Set switch
To Next Page
