Section 1

1.4 Inspection, Cleaning, and Lubrication

If operating properly, the Advanced Punch will punch the same types of copy

paper and cover materials handled by the printer and run at the same speed.

Hole quality will vary between different grades of paper.

The following maintenance should be performed according to the schedule.

AdvancedPunch Maintenance Schedule

Note: cycles = sheets of paper punched, not impressions.

Table 1.3.Periodic Maintenance

Table 1.4.Replacement Maintenance

Table 1.2 Customer Maintenance

Area/Unit Period See: Measures Remarks

Punch die pins 50K cycles Page 1-8 Lubricate Oil the punch pins

Area/Unit Period Measures Remarks

Aligner belt (green belt) 750K cycles Page 4-20 Inspect and clean Alcohol & rag

Aligner idler rollers 750K cycles Page 1-16 Inspect and clean Alcohol & rag

Aligner latching

mechanisms

750K cycles Page 1-25 Inspect

Back gauge mechanism 750K cycles Page 1-19 Inspect and clean Vacuum

Base 750K cycles Page 1-12 Clean Vacuum

Die guide 750K cycles Page 1-13 Clean Vacuum

Door closing latch 750K cycles Page 1-14 Inspect

Drive rollers 750K cycles Page 1-24 Inspect and clean Alcohol & rag

Hole alignment 750K cycles Page 1-9 Inspect

Idler rollers 750K cycles Page 1-20 Inspect and clean Alcohol & rag

Optical sensors 750K cycles Page 1-26 Clean Air

Paper path, aligner

panels

750K cycles Page 1-15 Inspect and clean Alcohol & rag

Paper path, bypass 750K cycles Page 1-28 Inspect and clean Alcohol & rag

Paper path, punch 750K cycles Page 1-29 Inspect and clean Alcohol & rag

Roller energy drive 750K cycles Page 4-35 Inspect

Timing belts 750K cycles Page 1-31 Inspect

Brake, punch drive 3,000K cycles Page 4-60 Inspect and clean

Clutch, Punch Drive 3,000K cycles Page 4-55 Inspect and clean

Punch drive cams 3,000K cycles Page 4-54 Lubricate Grease

Area/Unit Period Measures Remarks

Die set 500K cycles Page 1-5 Replace as needed

Back gauge mechanism 3,000K cycles Page 4-36 Replacement P/N 001N00516

GBC AdvancedPunch User Manual
