GBC AdvancedPunch User Manual

General Procedures
Advanced Punch Service Manual © Copyright 2009 GBC. All rights reserved. 6-5
6.3 GBC AdvancedPunch Input Component Control
Chain
No
Link
No
Component Name Description Signal Level
Not
Detected
Detected Meaning
040 100 AdvancedPunch
Ent SNR
AdvancedPunch Ent SNR
detects paper. *
High Low Paper
detected
040 101 AdvancedPunch
Path Ent SNR
AdvancedPunch Path Ent
SNR detects paper. *
High Low Paper
detected
040 102 AdvancedPunch
Ent SNR
AdvancedPunch Ent SNR
detects paper. *
High Low Paper
detected
040 103 AdvancedPunch
Exit SNR
AdvancedPunch Exit SNR
detects paper. *
High Low Paper
detected
040 104 AdvancedPunch
Path Exit SNR
AdvancedPunch Path Exit
SNR detects paper. *
High Low Paper
detected
040 105 AdvancedPunch
Bypass Ent SNR
AdvancedPunch
Path Exit SNR
AdvancedPunch Bypass
Ent SNR detects paper. *
AdvancedPunch Path Exit
SNR detects paper. *
High Low Paper
detected
040 106 AdvancedPunch
Bypass Exit SNR
AdvancedPunch Bypass
Exit SNR detects paper. *
High Low Paper
detected
040 200 AdvancedPunch
Dust Box Full SNR
AdvancedPunch Dust Box
detects Full status. *
Low High Full
040 201 AdvancedPunch
Die Set SW
Whether AdvancedPunch
Die Unit is correctly
detected (inserted).
Low High Miss Set
040 202 AdvancedPunch
Dust Box Set SW
Whether AdvancedPunch
Container is correctly
detected (inserted).
Low High Miss Set
040 203 AdvancedPunch
Bypass Chute Open
SNR
AdvancedPunch Bypass
Chute being open is
detected. *
High Low Open
040 204 AdvancedPunch
Rotation SNR
AdvancedPunch Cam in
its home position is
detected. *
Low High Home
040 300 AdvancedPunch
Front Door Open
SW
Status (open/close) of
AdvancedPunch Front
Door is detected. *
Low High Open
