Section 8
8-10 © Copyright 2009 GBC. All rights reserved. Advanced Punch Service Manual
8.2 Space Requirements
Figure 8.1 GBC Advanced Punch system Dimensions.
991.5
39.04
304.8
12.00
724.3
28.52
