General Procedures
Advanced Punch Service Manual © Copyright 2009 GBC. All rights reserved. 6-15
6.12 Specifications
To be determined:
Per the Technical Writing department, the recommendation is that "Specifications"
be contained and maintained in the User Manual only. The Technical Service
Manual should refer to the user manual.
Specifications are subject to change without notification
Table 6.5Specifications
115V MACHINES 230V MACHINES
Speed Up to 127 sheets per minute Up to 127 sheets per minute
Punch Sheet Size 8 -1/2" x 11 A4 - 21.59cm x 29.74cm
Punch Edge 11" edge of 8 -1/2" x 11 29.74 cm edge of A4
Paper Stock Refer to User Manual Refer to User Manual
Paper Bypass
Mode Sheet size
Paper sizes and stocks same as
printer
Paper sizes and stocks same as
printer
Punch Capacity Single Sheet Single Sheet
Power Supply 115V 60 Hz
Single Phase
Amps - 3.0 A
Watts - 340W
BTUs/Hour - 1160 BTU/HR
230V 50 Hz
Single Phase
Amps - 1.6 A
Watts - 340W
BTUs/Hour - 1160 BTU/HR
Safety TUV TUV/GS, CE
Dimensions 12" (W)
38.5" (H)
28.5" (D)
30.5cm (W)
97.8cm (H)
72.3cm (D)
Weight 154 lbs. 70 Kg
Shipping Weight 235 lbs. 115.5 Kg
Manufactured Made in Taiwan Made in Taiwan
