GBC AdvancedPunch User Manual

Section 6
6-6 © Copyright 2009 GBC. All rights reserved. Advanced Punch Service Manual
6.4 GBC AdvancedPunch Output Component Control
Chain
No
Link
No
Component Name Description
040 001 AdvancedPunch Stepping
Mot1(1000mm/s)
Operate the AdvancedPunch Stepping Mot1 at the speed
of 1,000mm/s. *
040 002 AdvancedPunch Stepping
Mot1(606mm/s)
Operate the AdvancedPunch Stepping Mot1 at the speed
of 606mm/s. *
040 003 AdvancedPunch Stepping
Mot1(350.3mm/s)
Operate the AdvancedPunch Stepping Mot1 at the speed
of 350.3mm/s. *
040 004 AdvancedPunch Stepping
Mot2(1000mm/s)
Operate the AdvancedPunch Stepping Mot2 at the speed
of 1,000mm/s. *
040 005 AdvancedPunch Stepping
Mot2(606mm/s)
Operate the AdvancedPunch Stepping Mot2 at the speed
of 606mm/s. *
040 006 AdvancedPunch Stepping
Mot2(350.3mm/s)
Operate the AdvancedPunch Stepping Mot2 at the speed
of 350.3mm/s. *
040 007 AdvancedPunch Transport Mot Operate the AdvancedPunch Transport Mot. *
040 008 AdvancedPunch Conduct AdvancedPunch operation (one time).
040 009 AdvancedPunch Cyclic Conduct AdvancedPunch operation successively at 3-
second intervals with Punch Mot, Punch Cl, Punch Brake,
and Punch Rotation SNR. *
040 010 AdvancedPunch Mot Operate the AdvancedPunch Mot. *
040 011 AdvancedPunch Cl Operate the AdvancedPunch Cl continuously. *
040 012 AdvancedPunch Cl Cyclic Repeat the set of AdvancedPunch Cl ON for 1 second
and OFF for 2 seconds. *
040 013 AdvancedPunch Gate Sol Operate the AdvancedPunch Gate Sol continuously. *
040 014 AdvancedPunch Gate Sol
Cyclic
Repeat the set of AdvancedPunch Gate Sol ON for 1 sec-
ond and OFF for 2 seconds. *
040 015 AdvancedPunch Backstop Sol Operate the AdvancedPunch Backstop Sol continuously. *
040 016 AdvancedPunch Backstop Sol
Cyclic
Repeat the set of AdvancedPunch Backstop Sol ON for 1
second and OFF for 2 seconds. *
