Section 6
6-4 © Copyright 2009 GBC. All rights reserved. Advanced Punch Service Manual
Tools Mode).
2. Select the "Machine Status" button on the UI Control Panel (the right side hard
button immediately below the touch display).
3. Select the "Tools" tab.
4. Scroll to the bottom of the "Features" group.
5. Select the "Maintenance/Diagnostics" button on the UI screen.
6. Select the "NVM Read/Write" button.
7. Enter Chain-Link values as directed in “Adjustments and Feature Control
General Procedures” on page 6-4 or as described in the NVM Settings List.
6.2 Adjustments and Feature Control General
Procedures
Item # Description Adjustment Procedure
GP1 Punch Counter
Enter Chain Link #769-253
(Value range from 0 to 18,000,000 and is resettable)
GP2
Adjusting counter for “Almost Full”
message
Enter Chain Link #769-244
Adjust value from nominal = 30 (x100 punch cycles) to higher value if
message occurs before Punch Waste Container is near full or to a lower
value if “Full Waste Container” message occurs before “Near Full”
message is displayed.
GP3
Punch “Almost Full" message ON/
OFF
Enter Chain Link # 769-250
0 = Detect
1 = Do not detect
GP4
Configuration recognition *related to
GP5
Enter Chain Link # 769-252
0 = Disabled
1 = Enabled
GP5
Configuration definition
*valid only if NVM 769-252 = 0
Enter Chain Link # 769-226
0 = No AdvancedPunch
1 = A4 AdvancedPunch connected
2 = Letter AdvancedPunch connected
GP6 AdvancedPunch SW version display Enter Chain Link #769-251
