GBC AdvancedPunch User Manual

General Procedures
Advanced Punch Service Manual © Copyright 2009 GBC. All rights reserved. 6-7
6.5 GBC AdvancedPunch NVM Setting List
Chain
No
Link
No
Parameter Name Feature Description Default
Value
Setting
Range
(Mini-
mum
Value)
Setting
Range
(Maxi-
mum
Value)
769 226 AdvancedPunch
Configuration
Determine whether AdvancedPunch is con-
nected or not, and the supported paper size,
when connected.
0: No AdvancedPunch
1: A4 AdvancedPunch connected
2: Letter AdvancedPunch connected
When the setting value of NVM769-252 is 0,
this NVM setting is valid.
00 2
769 243 AdvancedPunch:
Dust Box Miss Set
detection timer
Set the timer to detect the status that
AdvancedPunch Dust Box is not installed.
(Unit: 1sec)
When the setting value is 5, the Miss Set sta-
tus is detected 5 seconds after the Dust Box
is drawn out.
51200
769 244 AdvancedPunch:
Dust Box Near
Full
Set the number of punch operations to be
counted to determine AdvancedPunch Dust
Box Near Full.
(Unit: 100 times, The default is 3,000 times.)
30 1 100
769 245 AdvancedPunch:
Dust Box Punch
Count
Number of the counted punch operations
which produce the punch waste put into the
AdvancedPunch Dust Box.
(Unit: 0.1 time, The value of 10 indicates 1-
time punch.)
Decimals exist since different coefficients are
used depending on the paper type, which ar
0 0 120000
769 246 AdvancedPunch:
Coefficient for
Dust Box Punch
Count with Paper
Type (Light weight
paper / Plain
paper / backside
of used paper /
recycled paper /
punched paper)
Determine the coefficient value to be used at
counting the number of punch operations
which produce the punch waste put into the
AdvancedPunch Dust Box. This NVM item is
applied when the sheet to be punched is any
of light weight paper / plain paper / bac
10 1 200
769 250 AdvancedPunch
Dust Box Near
Full detectoion
Determine whether to detect AdvancedPunch
Dust Box Near Full.
0: Detect Near Full
1: Not detect Near Full
00 1
769 251 Advanced
Puncher Soft Ver-
sion
AdvancedPunch software version 0 0 31
769 252 Advanced
Puncher Auto
Recognition
Determine whether to automatically recognize
if AdvancedPunch is connected or not.
0: Auto recognition disabled (Follow the set-
ting of NVM769-226)
1: Auto recognition enabled
00 1
