4.6.3 Aligner Drive Belt (Green Belt) Replacement
Maintenance Schedule
Clean every 750K cycles. Refer to “Aligner Panel Inspection and Cleaning” on
page 1-15.
Procedure
Before replacing the green drive belts, remove the Aligner panels. See “Aligner Panel
Removal” on page 4-18. Then follow the procedures below for the entrance side or exit
side green drive belt service, “Paper Entrance Side Green Drive Belt Replacement”
on page 4-21 or “Paper Exit Side Green Drive Belt Replacement” on page 4-27.
Tools Required
• Phillips screw driver
• Nut drivers, 1/4 and 5/16"
• Hex wrenches, 5/64 and 9/64"
• Snap ring pliers
• E-Ring tool
• Twelve inch metal ruler or similar straight edge
Caution: Disconnect the Advanced Punch from power and retain the power cord
in your possession for your safety. Failure to observe this caution can result in
injury.
Tip: Empty the paper chip bin and replace it. This makes it easier to find
small parts that you may drop into the bin.
