Repair and Adjustment Procedures
Advanced Punc
h Service Ma
nual
© Copyright 2009 GBC. All rights reser
ved.
4-19
4.
Remov
e aligner latch stop b
y removing scre
ws [4]
5.
Remov
e the shaft n
ylon bushings [
3].
6.
Lift the Aligne
r panel up and unhook t
he tension spring from the panel [5].
7.
Remov
e the Aligner
panel out t
he front of the punch
.
8.
Re
verse the steps to install t
h
e Aligner panel.
[4]
[5]
[3]
[3]
76
