Repair and Adjustment Procedures

3. Remove the E-Ring at the opposite end of the shaft [1].

4. Slide the shaft out of the bearing bracket, away from the clutch end.

5. Slide the brake assembly off the shaft.

Figure 4.69 Shaft E-Ring.

6. To install the brake assembly, reverse these steps.

[1]
