Advanced Punch Service Manual
4.
Loosen the 2 soc
ket
head set screws[1]
on the pulley
and slide the pulle
y and
belt off the shaft
.
5.
Remove the motor mounting 4 nuts [2].
Figure 4.73 Motor Pulley and Mounting Nuts.
6.
T
o install the motor
, re
ve
rse these steps
.
[2]
[2]
[1]
121
