AdvancedPunch
The Punch Container for your AdvancedPunch is located at the front
of the machine’s base. The drawer should periodically be pulled out
and emptied. The AdvancedPunch uses a sensor to determine when
the punch container is full. Once the punch container becomes full
the LED light on the front panel of the AdvancedPunch will illuminate
and a message will appear on the printers user interface screen.
8. PUNCH CONTAINER
GB
Fault codes for the AdvancedPunch are displayed on the machine's UI
as an AdvancedPunch fault code. Listed below are fault codes that
apply specifically to the AdvancedPunch product.
Fault Codes
9. PROBLEM SOLVING
Probable Cause
No power, won’t punch
Die Set will not come out using
a moderate pull
Probable Cause
Power cord not attached to back of
machine or not properly plugged into
the wall Power On/Off Switch not
activated
The Die Set is in partial cycle. Turn
the Die Set knob (J3) to the HOME
position. Home position is when the
arrows line up. The Die Set should
now slide out easily.
Also see Paper Jams.
10. SPECIFICATIONS
Fault
Code
Possible Cause Recommended Solution
Open front door and
inspect for paper jam.
Remove papaerjam if found,
then close front door.
Close front door of
AdvancedPunch.
Install dieset or fully insert
dieset, then close front door.
Install and/or fully insert
punch container, then close
front door.
Empty punch container and
then re-install.
Empty punch container and
then re-install.
Jam is detected in
AdvancedPunch.
Front door of
AdvancePunch is not
closed.
Dieset is missing or not
fully installed.
Punch container is
mising or not fully
installed
Punch container is full.
Punch container is
near full.
040-100
040-101
040-900
040-901
040-300
040-940
040-941
040-942
140-700
Speed
Punch Sheet Size
Punch Edge
Paper Stock
Paper Bypass Mode
Sheet size
Punch Capacity
Power Supply
Electrical
Safety
Dimensions
Weight
Shipping Weight
Manufactured
115V Machines
Up to 127 sheets per minute
Letter - 8.5” x 11”
11”
20# bond to 80# cover
Paper sizes and stocks same as
printer
Single Sheet
115V, 60 Hz,
Single Phase
BTUs/Hour 1057BTU/HR
Watts 310W
Amps 2.8A
TUV/GS, CE
12” (30.5cm) (W) x 38.5” (97.8cm)
(H) x 28.5” (72.3cm) (D)
154 lbs. (70 Kg)
254 lbs. (115.5 Kg)
Assembled in Taiwan
