Repair and Adjustment Procedures
Advanced Punch Service Manual © Copyright 2009 GBC. All rights reserved. 4-7
To replace the door switch:
1. Open the front door.
2. Remove the 2 screws [1].
3. Unplug connectors from switch [2].
Figure 4.7 Door Switch.
[2]
[1]
