GE Datex-Ohmeda S/5 Series - Display Unit, Bottom Unit, F-CM(C)1 Rev.04 and 05

Spare Parts
5
Document no. M1144959-001
1.1.2 Display unit, bottom unit, F-CM(C)1 rev.04 and 05
Figure 3 Exploded view of the Display Unit, bottom unit
Item Description Order No. Replaced by
14 Screw-cross rec. c/s h, stzn, m3x6 61620
16 Shakeproof washer m3.2 63611
16 Shakeproof washer m3.2 63611
27 Washer-spring, M3,STZN(FZB),DIN127 634101
47 Cross cylinder-head screw M3x6 61721
47 Cross cylinder-head screw M3x6 61721
54 Central Processing Board, F-CM1 8000110 8001596
54 Central Processing Board, F-CM1 8001596 M1116607*
54 Central Processing Board, F-CM(C)1 for ... 05 and later M1116607*
55 NET cable, F-CM1 896527
56 NET Smart key cable, F-CM1 896528
57 Connector unit, NET, F-CM1 M1035234
58 Cross recess screw UNC 4-40 61841
