Datex-Ohmeda S/5 Compact Anesthesia and Compact Critical Care Monitors
44
Document no. M1144951-004
Table 8 Events transferred from S/5 Anesthesia Delivery Unit to the
S/5 Compact Anesthesia Monitor
4.4 Interfacing Dräger Cicero, Cato, Julian and
Narkomed 2C (by NAD)
It is possible to interface Dräger Cicero and Cato to the S/5 Compact Anesthesia Monitor or to
the S/5 Compact Critical Care Monitor via the Interface Module, E-INT / M-INT.
The parameters transferred to the S/5 Compact Anesthesia Monitor or S/5 Compact Critical
Care Monitor are summarized in Table 9 and Table 10.
NOTE: Some of the summarized parameters (waveforms or numerics) may not be available in
all device versions.
WARNING Always make sure that the combination complies with the international
safety standard IEC 60601-1-1 for medical electrical systems and with the
requirements of local authorities.
4.4.1 Interconnection
Use the INT-External Device Cable, except for Julian and Cicero EM, in which case use the
INT-Julian/Cicero EM cable.
Events transferred once a minute
Ventilator settings Ventilation (mode)
Tidal Volume
Minute Volume
Resp. Rate
I:E Times: inp
I:E Times: exp
InspPause
Ventilator measurements Ppeak
Pplat
Peep
Pmin
Fresh gas settings Agent name
Agent % in fresh gas
Total flow
O
2
flow
N
2
O flow
Air flow
Events transferred during system check
System check test results Gas Delivery: Agent
Gas Delivery: N
2
O
Leak Tests: AUTO
AUTO Leak (ml/min)
Leak Test: MAN
MAN Leak (ml/min)
Number of confirmed checklist items
Bypass Check
