GE Datex-Ohmeda S/5 Series - S;5 Compact Monitor Frame, F-CM(C)1 Rev. 01, Rev. 02, Rev. 03, F-CM(C)REC1 Rev.01

Spare Parts
15
Document no. M1144959-001
2.2 S/5 Compact Monitor Frame, F-CM(C)1 rev. 01, rev. 02,
rev. 03, F-CM(C)REC1 rev.01
Figure 8 Exploded view of S/5 Compact Monitor Frame
Item Description Order No. Replaced by
1 Frame assembly, F-CM1 896082
2 Handle, F-CM1, SPARE PART 8001521
3 Back plate (FRAME), F-CM1 8004019
4 Cross cyl. head screw M3x6 tufflock 617210
5 AIM-N-cable,Network connection cable,
0.23m,UTP T568A C5
908680
6 Connector-case, modular coupler, 8-positon,
in-line
548737
7 Connector shield, F-CM1 rev. 01 8004290
8 NET smart key cable 2, F-CM1 8000701
