3.2.2 Recommended parts
3.2.3 Before beginning
•
Make sure that the monitor is switched to standby.
• Disconnect the power cord and press the service reset switch until the LED next to it turns
off.
• If the monitor is connected to the Datex-Ohmeda Network, disconnect the Mon-Net cable
from the Frame Unit. Take out any memory cards, if installed.
• Detach the Display Unit from the Frame Unit.
• Open the Display Unit by detaching the Front Unit.
NOTE: Wear a static control wrist strap when handling PC boards. Electrostatic discharge may
damage components on the board.
3.2.4 Visual inspection
1. DC/DC power supply board
Disconnect the DC/DC power supply board. Check the Display Unit – Frame Unit
connector under the board:
• screws are tightened properly
• the connector is clean and intact
"
2. Central Processing Board
Check the Central Processing Board in the Display Unit:
• screws are tightened properly
• cables are connected properly
• all ICs that are on sockets are attached properly
"
3. DC/DC power board
Reconnect and check the DC/DC Power Board:
• screws are tightened properly
• all connectors are clean and intact
• the cables are attached properly
"
Part Order No. Notes
Display Unit Fan filter 897010
Recorder paper 74205 for recorder unit
