Functional check
53
Document no. M1144951-004
5 Functional check
These instructions include procedures for a functional check for Datex-Ohmeda S/5 Compact
Anesthesia Monitor and S/5 Compact Critical Care Monitor. The functional check is
recommended to be performed after monitor installation.
These instructions include a “Functional check form, Datex-Ohmeda S/5 CAM, CCCM” to be
filled in when performing the procedures. The symbol
" in the instructions means that the
performed procedure should be signed in the check form. The procedures should be performed
in ascending order, bypassing those that are not applicable for a particular monitor.
All menu selections related to Datex-Ohmeda products are written in following typeface:
e.g. Parameters - Gas Unit.
As you enter the service menus, you need the following passwords:
Monitor Setup - Install/Service (password 16-4-34) - Service (password 26-23-8)
In case you evaluate the measurement accuracy with a patient simulator, add simulator’s
accuracy specification to the one of the monitor.
An electrical safety check and a leakage current test are recommended to be performed prior
to the monitor installation.
5.1 Recommended tools
NOTE: Use only properly maintained, calibrated and traceable measurement equipment for
the specified calibrations and adjustments to ensure accuracy.
For product(s) Tool Order No.
Airway modules
Compact Airway Module,
E-CAiO(VX)/ M-CAiO(VX)
Calibration gas and regulator 755583/755534*
Compact Airway Module, E-COVX/
M-COVX
Calibration gas and regulator 755587/755534*
Compact Airway Module, E-CO(V),
M-C, M-CO(V)
Calibration gas and regulator 755581/755534*
E-miniC/ M-miniC Calibration gas and regulator 755580/755534*
Compact Airway Module, E-COVX,
E-CAiOVX, M-COVX, M-CAiOVX
Sampling line, 2 m 73318
All Airway modules w/ (V) Spirometry tube, 2 m 890031
D-lite 733950
Hemodynamic modules
Hemodynamic modules w/ (P),
M-NIBP
NIBP cuff and hose 2753E (cuff)
877235 (hose)
Pressure manometer
Hemodynamic modules w/
(P)E-PSMP
InvBP transducer 70077-001
