GE Multilin 750/760 Feeder Management Relay 3-7
3 INSTALLATION 3.2 ELECTRICAL
3
3.2ELECTRICAL 3.2.1 TYPICAL WIRING
Figure 3–9: TYPICAL WIRING DIAGRAM
Courtesy of NationalSwitchgear.com
