E.P.A (Servo Travel/Limit)
WIZ.
CH 1.
CH 2.
CH 3.
CH 4.
CH 5.
150%
150%
150%
150%
150%
INC
RES
DEC
100%
100%
100%
100%
100%
100%
100%
100%
100%
150%
150%
150%
150%
150%
100%
E.P.A
– LIMIT LIMIT +
– TRAVEL+
NEXT
Tip
Press the NEXT button on the right side of the display
to scroll through the channel screens.
The travel and limitation are shown separately for
each side in this display. The setting range in both
cases is 0 - 150% of normal travel.
The set values always refer to the settings in the BASE
submenu REV/SUB (page 64).
To change a value, touch the desired option field, for
example:
WIZ.
CH 1.
CH 2.
CH 3.
CH 4.
CH 5.
150%
150%
150%
150%
150%
INC
RES
DEC
100%
100%
100%
100%
100%
100%
100%
100%
100%
150%
150%
150%
150%
150%
100%
E.P.A
– LIMIT LIMIT +
– TRAVEL+
NEXT
Press
The selected field will highlight blue:
WIZ.
CH 1.
CH 2.
CH 3.
CH 4.
CH 5.
150%
150%
150%
150%
150%
INC
RES
DEC
100%
100%
100%
100%
100%
100%
100%
100%
100%
150%
150%
150%
150%
150%
100%
E.P.A
– LIMIT LIMIT +
– TRAVEL+
NEXT
Press the INC button at the right edge of the display
to increase the value of the active option field. Press
the DEC button to reduce the value of the active op-
tion field. Press the RES button to reset the changed
value back to the default. Alternatively, press the ar-
row keys ( pq ) to the left of the display screen to
achieve the same increase/decrease result.
Once all you have adjusted all of your servos, press
the WIZ. button to bring up the D/R,EXP display:
D/R,EXP (Dual Rate/Expo)
The dual rate/expo function allows you to switch or
influence the control deflections and characteristics
for the control functions of roll, nick and tail rotor, i.e.
control functions 2 - 4 through switch.
Dual Rate allow one or more controls to have less (or
more) control authority at the flick of a switch.
The control deflections can be set for each switch
position between 0 and 125% of the normal control
travel.
EXP (exponential curve) limits how much the servo
moves within programmed stick parameters. This is
used to help slow down the servos reaction to stick
input, allowing a more sensitive model control in the
central position of the respective control function (roll,
nick and tail rotor) for values greater than 0% without
having to do without the complete deflection in the
end position of the control stick.
Conversely, the effect of the control around neutral
position increases for values less than 0% and de-
creases in the direction of the full deflection. The pro-
gression can be set from -100% to +100%; 0% cor-
responds to the normal linear control characteristic.
The EXP setting always acts directly on the corre-
sponding control function independent of whether
it affects the individual servo or several servos by
means of complex mixing and coupling functions.
By default, the dual rate and/or expo values are set
for each control side. Press to change the option SYM
from OFF to ON:
WIZ.
CH
D/R
EXP
CTL
ROLL
+100%
+100%
NULL
INC
RES
DEC
PHASE 1
000%
000%
SYM
OFF
D/R,EXP
Press
A symmetrical (joint) setting of both control sides is
now possible.
The curve characteristics are shown in the graphic on
the left of the display screen the curve characteristics
are shown directly.
Tip
These options and settings can be changed via the
FUNCTION submenus PHASE and D/R,EXP (page
120 and 124).
Programming
To enter programming parameters on the different
ROLL, NICK and TAIL channels, press the button to
the right of the CH (channel) line:
