4.2 Temperature Controller/Servo/Inverter Connection 4-15
Available Device Memory
The available setting range of device memory varies depending on the controller model. Be sure to set within the range
available for the controller to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Device Memory (Parameter Type ID) TYPE Remarks
000 (NA area) 00H Double-word
001 (H/W information) 01H Double-word, read only
002 (calendar time setting) 02H Double-word
021
(AI setting) high-resolution monitor: for standard
input
03H Double-word
022 (AI setting) special monitor 04H Double-word
023 (AI setting) high-resolution monitor: for option input 05H Double-word
041 (AUX-IN setting) 06H Double-word
045 (AO setting) 07H Double-word
061 (DO setting) 08H Double-word
071 (TP setting) 09H Double-word
074 (zener barrier adjustment value) 0AH Double-word
0A1 (communication setting: for ME200) 0BH Double-word, read only
0A2 (communication setting: for MR200) 0CH Double-word, read only
0A3 (communication setting: front port) 0DH Double-word, read only
0C1 (system status) 0EH Double-word, read only
0C3 (calendar time display) 0FH Double-word, read only
0C4 (log: system alarm) 10H Double-word
0C5 (log: AI alarm) 11H Double-word
0C6 (log: AUX-IN alarm) 12H Double-word
0E1 (AI status) 13H Double-word, read only
0E2 (AUX-IN setting) 14H Double-word, read only
0E3 (AO status) 15H Double-word
0E5 (DI status) 16H Double-word, read only
0E6 (AO status) 17H Double-word
0E7 (TP status) 18H Double-word
0E8 (zener barrier adjustment count) 19H Double-word, read only
0F1 (communication setting in use: for ME200) 1AH Double-word, read only
0F2 (communication setting in use: for MR200) 1BH Double-word, read only
0F3 (communication setting in use: front port) 1CH Double-word, read only
201 (PID_A setting) 1DH Double-word
202 (PID_A constant) 1EH Double-word
203 (PID_A monitor) 1FH Double-word, read only
211 (PID_CAS setting) 20H Double-word
212 (PID_CAS constant: master side) 21H Double-word
213 (PID_CAS constant: slave side) 22H Double-word
214 (PID_CAS monitor) 23H Double-word, read only
234 (Ra_PID setting) 24H Double-word
235 (Ra_PID constant) 25H Double-word
236 (Ra_PID monitor) 26H Double-word, read only
241 (UP_PID setting) 27H Double-word
242 (UP_PID constant) 28H Double-word
243 (UP_PID monitor) 29H Double-word, read only
301 (TBL/TBR setting) 2AH Double-word
801 (user-defined parameter) 2BH Double-word
802 (user-defined parameter) 2CH Double-word
803 (user-defined parameter) 2DH Double-word
804 (user-defined parameter) 2EH Double-word
805 (user-defined parameter) 2FH Double-word
806 (user-defined parameter) 30H Double-word
80D (user-defined parameter) 31H Double-word
80E (user-defined parameter) 32H Double-word
E01 (user-defined parameter) 33H Double-word
E02 (user-defined parameter) 34H Double-word
E04 (user-defined parameter) 35H Double-word
E05 (user-defined parameter) 36H Double-word
E06 (user-defined parameter) 37H Double-word
E07 (user-defined parameter) 38H Double-word
E08 (user-defined parameter) 39H Double-word
