4-16 4. Azbil
Address denotations
On the signal name reference list, every group ID is designated as “001”. To access any group ID other than “001”, input the
desired ID via manual operation.
aaabbbcc
E0A (user-defined parameter) 3AH Double-word
E12 (user-defined parameter) 3BH Double-word
E13 (user-defined parameter) 3CH Double-word
E14 (user-defined parameter) 3DH Double-word
E15 (user-defined parameter) 3EH Double-word
610 (user-defined parameter) 3FH Double-word
C00 (pattern setup) 40H Double-word
CF1 (pattern FB monitor) 41H Double-word, read only
C01 (segment setup) 42H Double-word
C02 (segment setup) 43H Double-word
C03 (segment setup) 44H Double-word
C04 (segment setup) 45H Double-word
C05 (segment setup) 46H Double-word
C06 (segment setup) 47H Double-word
C07 (segment setup) 48H Double-word
C08 (segment setup) 49H Double-word
C09 (segment setup) 4AH Double-word
C0A (segment setup) 4BH Double-word
C0B (segment setup) 4CH Double-word
C0C (segment setup) 4DH Double-word
C0D (segment setup) 4EH Double-word
C0E (segment setup) 4FH Double-word
C0F (segment setup) 50H Double-word
C10 (segment setup) 51H Double-word
C11 (segment setup) 52H Double-word
C12 (segment setup) 53H Double-word
C13 (segment setup) 54H Double-word
C14 (segment setup) 55H Double-word
C15 (segment setup) 56H Double-word
C16 (segment setup) 57H Double-word
C17 (segment setup) 58H Double-word
C18 (segment setup) 59H Double-word
C19 (segment setup) 5AH Double-word
C1A (segment setup) 5BH Double-word
C1B (segment setup) 5CH Double-word
C1C (segment setup) 5DH Double-word
C1D (segment setup) 5EH Double-word
C1E (segment setup) 5FH Double-word
C1F (segment setup) 60H Double-word
Device Memory (Parameter Type ID) TYPE Remarks
