4-20 4. Azbil
Address denotations
On the signal name reference list, every group ID is designated as “001”. To access any group ID other than “001”, manually
input the desired ID.
aaabbbcc
PLC_CTL
Macro command “PLC_CTL F0 F1 F2”
Return data: Data stored from temperature controller to V series
F05 (user-defined area) 3AH Double-word
F06 (user-defined area) 3BH Double-word
Device Memory (Parameter Type ID) TYPE Remarks
Item ID
Group ID
Parameter type ID
Contents F0 F1 (= $u n) F2
ISaGRAF application
Start/stop
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 0
n + 2
0: Stop
1: Start
ISaGRAF application
Current status
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 1
n + 2
0: Stop
1: Run
Reserve for parameter backup
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 2
