4.2 Temperature Controller/Servo/Inverter Connection 4-21
4.2.11 AHC2001+DCP31/32
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Controller
AHC2001 SCU unit setting
(Underlined setting: default)
*1 xx: Unit position 01 to 10H
The unit position varies depending on the mounting position of the SCU unit.
DCP31/32
Setting group: Make the following setting on the setup data.
(Underlined setting: default)
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 9600 / 19200 / 38400 bps
Data Length 7/ 8
bits
Stop Bit 1
/ 2 bits
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Parameter
Type ID
Group ID Item ID Setting Items Contents Remarks
Exx
*1
002
01 Baud rate
9600 bps
19200 bps
38400 bps
02 Data bit length
7: 7 bits
8: 8 bits
03 Parity
0: None
1: Even
2: Odd
04 Stop bit
1: 1 bit
2: 2 bits
05 Half duplex / full duplex
0: Half duplex
1: Full duplex
Half duplex: 2-wire connection
Full duplex: 4-wire connection
07 Protocol selection 2: CPL server
Item Indication Setting Remarks
Communication
address
C84 1 to 31 Communication is disabled when “0” is set.
Baud rate C85
0: 9600 bps, even parity, 1 stop bit
1: 9600 bps, without parity, 2 stop bit
2: 4800 bps, even parity, 1 stop bit
3: 4800 bps, without parity, 2 stop bit
Data type C93 0: Additional terminal
