4-24 4. Azbil
4.2.12 DCP31/32
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Controller
Setting group: Make the following setting on the setup data.
(Underlined setting: default)
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600 bps
Data Length 8
bits
Stop Bit 1
/ 2 bits
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Item Indication Setting Remarks
Communication
address
C84 1 to 31 Communication is disabled when “0” is set.
Baud rate C85
0: 9600 bps, even parity, 1 stop bit
1: 9600 bps, without parity, 2 stop bit
2: 4800 bps, even parity, 1 stop bit
3: 4800 bps, without parity, 2 stop bit
Data type C93 0: Additional terminal
Device Memory TYPE Remarks
--- 00H
